Product information
Overview
Teranex Mini SDI to Analog 12G
Convert from 12G-SDI to Analog. Use SD, HD, 6G and 12G-SDI rates and convert to analog video output. Built in down converter lets you connect Ultra HD sources to component video equipment in SD or HD. Allows you to connect analog equipment including Betacam SP, VHS, and video monitors.
Technical specifications
- SDI Video Inputs: 1 x 12G-SDI SD/HD/2K/4K auto switching.
- SDI Video Outputs: 1 x 12G-SDI loop output.
- Analog Video Outputs: Composite, Y/C or Component.
- Analog Audio Outputs: 2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for timecode output.
- Digital Audio Outputs: 4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for timecode output.
- Embedded Audio Support: 16 channels.
- Multi Rate Support: Automatic switching between SD/HD/2K and 4K.
- Updates and Configuration: USB or Ethernet.
- Reclocking: Yes
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards: 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
- 2K Video Standards: 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI
- Ultra HD Video Standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
- 4K Video Standards: 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI
- SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10
- SDI Video Rates: SDI video connections are auto switching between standard definition SDI, high definition level A and level B 3G-SDI, 6G-SDI, and 12G-SDI.
- SDI Video Sampling: 4:2:2 and 4:4:4
- SDI Audio Sampling: Television standard sample rate of 48 kHz and 24-bit.
- SDI Color Precision: 4:2:2 and 4:4:4
- SDI Color Space: YUV
- Analog Video Standards: 525i59.94 NTSC, 625i50 PAL
- Analog Color Space: REC 601, REC 709
- Analog Color Precision: YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.
- Software Control: Mac™ and Windows™ software upgrade via USB and Ethernet.
- Internal Software Upgrade: Via included updater application.
- Basic Settings Control: Mini Switches, USB and Ethernet via free software utility.
- Optional Front Panel Control: Front mounted Smart Panel with LCD, rotary knob and six settings buttons
- Power Supply: 1 x built-in international AC power supply with IEC C14 inlet. IEC Power cable required. 100 - 240V AC Input.
- Power Over Ethernet: Can be powered via 48V DC using PoE+ (power over ethernet).
- Power Consumption: 16 Watts
- Operational Voltage Range: 100 - 240V AC
- Operating Temperature: 0° to 40°C (32° to 104°F)
- Storage Temperature: -20° to 60°C (-4° to 140°F)
- Relative Humidity: 0% to 90% non‑condensing
For further information, see Blackmagic Design.
