Mini Converter SDI to Audio
The perfect way to de‑embed audio from any SDI source in SD and HD formats up to 1080p60! Audio is output on ¼" connectors for balanced analog and AES/EBU audio output to equipment such as mixers, analog decks, audio monitors and more. Mini Converter SDI to Audio is the ideal SD/HD SDI audio de‑embedder for when you don’t need the cost of the Ultra HD model!
Technical specifications
- SDI Video Inputs: 1 x SD, HD or 3G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
- SDI Video Outputs: 1 x SDI Loop Output.
- Analog Audio Outputs: 4 channels of professional balanced analog audio.
- Digital Audio Outputs: 8 channels of professional balanced AES/EBU audio.
- SDI Redundant Inputs: Automatically switches over if main SDI input is lost.
- Multi Rate Support: Auto detection of SD, HD or 3G‑SDI.
- Updates and Configuration: Via USB 2.0 high speed. (480 Mb/s)
- Reclocking: Yes
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
- 2K Video Standards: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
- SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M level B, SMPTE 425M level B, ITU‑R BT.656 and ITU‑R BT.601
- SDI Video Rates: SDI video inputs are automatically detected between standard definition, high definition and level B 3G‑SDI.
- SDI Video Sampling: 4:2:2, 4:4:4
- SDI Audio Sampling: Television standard sample rate of 48 kHz and 24 bit.
- SDI Color Precision: 4:2:2, 4:4:4
- SDI Color Space: YUV, RGB
- SDI Auto Switching: Automatically selects between SD, HD, and 3G‑SDI.
- Software Control: Mac™ and Windows™ software upgrade via USB.
- Internal Software Upgrade: Via included updater application.
- Power Supply: +12V universal power supply included with international socket adapters for most countries. Cable tie point.
- Power Consumption: 5.52 Watts
- Operational Voltage Range: 12 ‑ 15V DC
- Operating temperature: 0° to 40° C (32° to 104° F)
- Storage temperature: -20° to 45° C (-4° to 113° F)
- Relative Humidity: 0% to 90% non‑condensing
For further information, see Blackmagic Design.
